Non-PVC Soft Bag IV Solution Production Line

Application

Non-PVC soft bag IV solution production line is the latest production line with most advanced technology. It can automatically finish film feeding, printing, bag making, filling ans sealing in one machine.

It can be applied to 50-5000ml Non-PVC soft bag for general solution, special solution, dialysis solution, parenteral nutrition, antibiotics, irrigation and disinfectant solution etc.

It can supply you different PP bag design with single boat type port, single/double hard ports, double soft tube ports etc.

Main Features

1. 100% film utilization: No waste edge between bags, reducing both material and energy consumption.

2. Reliable heating and welding system: Leakage rate less than 0.03%.

3. Quick changeover: 0.5-1 hour to switch from one size to another.

4. Compact structure, reduce 1/3 length of the machine, save room space and running cost.

5. Stable running and transmission system: only need 1 control system, 1 HMI and 1 operator.

6. Safe filling nozzle: No solution overflows, no particles generation.

7. Auto detection and faulty rejection system.
